Canvas A3 · 20.2
An A3-format project display for replacing low-frequency printed posters. Specify a complete unit or a panel/TCON integration as separate supply scopes.
Evaluate the right configuration.
Sample; batch timing to confirm
Request an evaluation sample. Source documents differ on volume-production timing; confirm current batch availability before committing a rollout.
Project pricing · Hardware, options and delivery itemized separately.
Compare all models
Download specification · PDFSpecifications
| Model | AES-2020V |
|---|---|
| Display | E Ink Spectra 6 |
| Diagonal | 20.2″ |
| Resolution | 1530 × 2160 |
| Aspect ratio | 1:√2 |
| Pixel density | 131 ppi |
| Active display area | 297.28 × 419.69 mm |
| Unit dimensions | 375.6 × 480.2 × 29 mm (reference configuration) |
| Power | External battery pack or mains, by configuration |
| Image updates | Project firmware and content-update workflow agreed at demonstration |
Dimensions & installation
Confirm the mechanical drawing and installation accessories before ordering.
Included in the configuration
- Spectra 6 display and controller
- Metal enclosure in complete-unit configuration
- Power, software and mounting scope listed in the quote
Project options
- Anti-glare cover configuration
- Enclosure branding and mounting
- Demonstrated CMS or API integration
Content updates for this model
Project firmware and content-update workflow agreed at demonstration
Your content, this device
Test image rendering and a complete refresh using the selected sample and firmware.
Confirm software and compatibility
App availability, scheduling, gateways, groups and API access depend on this model and the agreed package; they are not common standard features across the range.
MagiRealm
The planned content engine is separate from the supplied device app and is not part of the hardware commitment.
Before your sample or project order
A retained image does not need continuous panel power. The controller and wireless connection can still consume power. Battery runtime depends on firmware, refresh frequency and connectivity. Confirm current certification, warranty and software scope for the ordered configuration.
Can I request one sample?
Request an evaluation sample. Source documents differ on volume-production timing; confirm current batch availability before committing a rollout.
Does the price include software and shipping?
The quotation separates hardware, optional software, customization and delivery. Sample pricing is confirmed for the selected configuration; freight, insurance and destination taxes are not implied.
Can it play video or rapid slideshows?
No. Color E-Ink is intended for still images and low-frequency changes. Ask to see a full refresh with your artwork before choosing it for time-sensitive signage.
Are scheduling and fleet management standard?
Not across every configuration. These functions require a confirmed software package and demonstration. Roadmap features are not included in the hardware promise.
Tell us what you want to display.
We will align the model, quantity, destination and delivery scope.
