Canvas 13.3 CNC
A CNC aluminium color E-Ink frame for product evaluation, gallery-style displays and branded spaces. Start with a sample before specifying a project batch.
Evaluate the right configuration.
Sample / project quotation
Sample and batch orders are available by quotation. Configuration, production lead time and shipping are confirmed before order acceptance.
Request Sample Quote · Hardware, options and delivery itemized separately.
Compare all models
Download specification · PDFSpecifications
| Model | AES-1330CNC |
|---|---|
| Display | E Ink Spectra 6 |
| Diagonal | 13.3″ |
| Resolution | 1600 × 1200 |
| Aspect ratio | 4:3 / 3:4 |
| Pixel density | 150 ppi |
| Active display area | 202.8 × 270.4 mm |
| Unit dimensions | Confirmed for the selected enclosure and mounting |
| Power | 5,000 mAh rechargeable battery; 10,000 mAh option |
| Image updates | Wi-Fi image push and TF-card image import |
Dimensions & installation
Discuss the wall, shelf or suspended fixture before ordering. Mounting interfaces can be adapted to the project; do not assume every bracket is included.
Included in the configuration
- 13.3-inch E Ink Spectra 6 display
- CNC aluminium enclosure
- Rechargeable battery and Wi-Fi configuration
- Factory firmware agreed for the project
Project options
- 10,000 mAh battery
- Enclosure finish and mounting adaptation
- BLE, wired or PoE integration, subject to engineering review
- Customer firmware loaded at the factory
Content updates for this model
Wi-Fi image push and TF-card image import
Your content, this device
Test image rendering and a complete refresh using the selected sample and firmware.
Confirm software and compatibility
App availability, scheduling, gateways, groups and API access depend on this model and the agreed package; they are not common standard features across the range.
MagiRealm
The planned content engine is separate from the supplied device app and is not part of the hardware commitment.
Before your sample or project order
A retained image does not need continuous panel power. The controller and wireless connection can still consume power. Battery runtime depends on firmware, refresh frequency and connectivity. Confirm current certification, warranty and software scope for the ordered configuration.
Can I request one sample?
Sample and batch orders are available by quotation. Configuration, production lead time and shipping are confirmed before order acceptance.
Does the price include software and shipping?
The quotation separates hardware, optional software, customization and delivery. Sample pricing is confirmed for the selected configuration; freight, insurance and destination taxes are not implied.
Can it play video or rapid slideshows?
No. Color E-Ink is intended for still images and low-frequency changes. Ask to see a full refresh with your artwork before choosing it for time-sensitive signage.
Are scheduling and fleet management standard?
Not across every configuration. These functions require a confirmed software package and demonstration. Roadmap features are not included in the hardware promise.
Tell us what you want to display.
We will align the model, quantity, destination and delivery scope.
